Sintered Bronze Filters
Porous Sintered Bronze Filter Elements for Controlled Filtration, Air/Oil Separation and Industrial Fluid Applications
Sintered bronze filters are porous metal filter components manufactured by compacting bronze powder into a defined shape and sintering it under controlled conditions. The interconnected pores provide a filtration path through the metal structure while maintaining the mechanical advantages associated with a rigid metallic filter element. Sintered Metal Filters are equipped with durable and effective sintered candles, these filters are very much effective for the filtration process. Sintered Bronze filter components are produced utilizing powder metallurgical system. All these items are utilized for filtration motivation behind fluids and gases. We are engaged in offering a wide array of Sintered Bronze Filter Elements.
We manufacture and supply sintered bronze filter components for industrial, OEM and replacement applications, with material, geometry, porosity and filtration characteristics selected according to the customer’s application requirements.
What is a Sintered Bronze Filter?
A sintered bronze filter is a porous metallic filter element produced through powder metallurgy.
Unlike conventional woven or perforated filters, the filtration structure is formed by interconnected pores within the sintered metal body.
A typical manufacturing sequence involves:
Bronze powder → Powder blending → Tooling/compaction → Green component → Sintering → Sizing/finishing → Inspection → Final filter
The final component can be produced in different geometries depending on the filtration system, installation arrangement and required flow path.
Why Bronze?
Bronze can be selected when a combination of:
- controlled porosity
- corrosion resistance appropriate to the service environment
- metallic construction
- mechanical rigidity
- reusable/cleanable filter construction
- dimensional stability
- application-specific filtration characteristics is required.
The actual suitability of a bronze filter depends on the bronze composition, pore structure, fluid, temperature, pressure, filtration requirement and operating conditions.
How Sintered Bronze Filters Work
The interconnected pore network allows the process medium to pass through the porous metal structure while particles are retained according to the filter’s pore characteristics and operating conditions.
- Longer service life
- Withstand very high pressure
- Easy to use
- Withstands Temperatures up to 2500C
- High Dirt Holding Capacity
- Stable Pore Size due to Sintering Process
- Withstand Very High Pressure
- Low Pressure Drop
- Available in various sizes up to 1 meter L
- Filtration Levels: 1 to 100 microns
- Easily Cleanable
- Corrosion Resistant
- High Permeability
